POL SERIES / POLISHING TECHNOLOGY
Threshing and rubbing machines
These type of machines are specially designed for rubbing and/or polishing of seeds. By using beaters with rubber flaps the rubbing is relatively smooth but still very effective and the threshing compartment remains very clean while the seeds can not stick into brushes like with other type of rubbing machines. The machine is designed for quick, easy and thorough cleaning.
The POL 200B and 300B are ideal for rubbing small seed lots in vegetable or flower seed (breeding) because the operation is with batches of seeds. While the POL 300C is a continuously operating machine for bigger seed lots up to 500 kgs/hour. These machines operate very smoothly to tavoid damaging the seeds and is very easy to adjust.
POL SERIES PRODUCTS BY CAPACITY
|POL SERIES||POL 2.0||POL 3.0||POL 3.0 C|
|Drum diameter (mm)||180||380||300|
|Drum length (mm)||200||700||660|
|Length of machine (mm)||600||1.150||1.650|
|Width of machine (mm)||300||950||700|
|Height feeding funnel (mm)||850||1.300||2.160|
|Power supply||0,37 kW - 230 volt||1,5 kW - 230 volt||5,5 kW - 400 volt|
POL 330B can be delivered for semi-automatic operation; the machine is inter-active with the operator.
POL 300C, depending on the level and type of debris the feeding can be done by a VIDOS vibrating feeder, by belt feeder or by hand.
The rubbing process is very smooth as it done by long rubber flaps that turn arround in a cylinder.
CLEAN & EASY TO CLEAN
The cylinder is split in two halves. The top half is mounted in the machine and the bottom half can be opened very easily. It is hanging in two hinges so that the inside of the cylinders is very easy accessible for inspection and thorough cleaning.
The process is controlled by a timer so the polishing time is for every seed lot the same and no risk of damaging the seeds because of too long rubbing.
HOW IT WORKS?
The rubbing process is very smooth as it is done by long rubber flaps that turn around in a cylinder. The cylinder is split in two halves. The top half is mounted in the machine and the bottom half can be opened very easily. It is hanging in two hinges so that the inside of the cylinder is very easy accessible for inspection and thorough cleaning.
POL 3.0 C: The bottom half of the cylinder is made of perforated steel plate. Through this part the dust is sucked away so the machine operates very clean. Because it is a continuous system and not batch type. The capacity is high for a compact machine like this.
• Very smooth polishing/rubbing process, no damage to the seeds
• Very easy accessible and thorough to clean
• Very easy operation and settings, all are adjustable and reproducible
POL 200B and 300B
• Exchangeable beater types
• Stronger or smoother flaps or even steel beaters
POL 300B and 300C
• Very clean operation, most of the dust is eliminated as the bottom of the rubbing cylinder is made of perforated steel.
SMALL SEED LOTS
The POL 200B and 300B are batch type machines for smaller seed lots. Can even be used for small plant parts or even one ear of corn etc.
BIG SEED LOTS
300C is a continuous system for bigger seed lots up to 500 kg/hour. The capacity of the 300C is high for a compact machine like this.
The POL-300C is a very smooth rubbing machine designed to process seeds like tomato and carrot for debearding, or in melon seeds, squash, cucumber, egg-plant to remove hulls and skin sticking to those type of seeds. POL 300 can be used for lighter polishing in most other seeds as well.
