MULTICOATER CM SERIE / TREATMENT TECHNOLOGY
Multicoater CM Serie
The All in One Concept
The PETKUS MultiCoater CM series redefines chemical seed treatment.
The key feature is the unique air management with a sophisticated air cushion technology that turns the PETKUS/ROEBER coater into a highly advanced and modern machine.
Air is blown into the mixing chamber through nozzles and via an adjustable gap between rotor and stator wall creating a protective layer comparable to an airbag. This air cushion reduces friction which usually causes some mechanical stress on the seeds. The result is abrasion.
In contrast, the CM series with its very gentle treating and coating process ensures reduced dust-off emissions that is compliant to international standards for certified seeds (e.g. Heubach). The results of this kind of seed treatment is: film coating, encrusting and pelleting are considerably improved comparing to traditional batch treaters.
CM SERIE PRODUCTS BY CAPACITY
|CM SERIE||CM lab version||CM 25||CM 100|
|Performance (t/h)||up to 1,8||up to 8,5|
|Air Volume (m3/h)||up to 3 |
|up to 8 |
|Barrel capacity (kg)||25||100|
HOW DOES IT WORK?
The MultiCoater works according to the rotor-stator principle.
1. Desired seed batch is loaded into the mixing chamber with a precise electropneumatic (weighing scale) gravimetric dosing unit.
2. During the application phase various liquid chemicals and coating powders are delivered by the efficient and accurate dosing system working on a loss in weight principle. Coating materials can be applied simultaneously or in a sequence mode. All dosing rates are measured and recorded in the software therefore the actual and target values can be easily compared and automatically adjusted throughout the ongoing process.
3. Specially designed spraying disc creates an extremely fine dispersion of the chemicals to be distributed equally (uniformly) on the seed surface due to a wide spraying angle (homogeneous seed to seed distribution).
4. Optimal mixing is done by deflectors which are manufactured of a special energy absorbing polymer. Their aerodynamic shape is designed to guide seeds into the middle of the machine ensuring excellent flow and improved seed coverage.
5. Treated seeds can be dried before their discharge. An easily adjustable airflow passes and penetrates the coated product which efficiently dries the seeds surface.
6. The rotor and stator are made of smooth, electro-polished stainless steel, reducing chemicals residue adherence inside the mixing chamber. Easy cleaning after the treatment is supported by the fully openable lid.
• Improved abrasion value and reduced mechanical stress
• Treatment and drying in one step
• Improvement of flow properties
• Innovative air flow technology with air-cushion effect
• Fluid metering using MID
• Self-learning system with fully automatic adjustments
• Rotor-stator with self-cleaning effect
• Maximum recipe flexibility and recipe saving
• Easy operation by touch panel
• Process data recording and documentation
• Absolutely uniform and complete coating of the grain surface
• Easy maintenance and accessibility through 180 degree swivel lid
• Fast coupling and decoupling of the PCA connections
